Engine
Engine type
Liquid-cooled, 4-stroke Single
Displacement
449cc
Bore x stroke
96 x 62.1 mm
Compression ratio
12.5:1
Valve/Induction system
DOHC, 4 valves
Fuel system
Fuel injection: 44 mm x 1
Ignition
Digital DC-CDI
Starting
Electric
Lubrication
Forced lubrication, semi-dry sump
Frame & Dimensions
Frame type
Aluminium Perimeter
Rake/Trail
Trial: 115 mm
Wheel travel - front
305 mm
Wheel travel - rear
307 mm
Tyre - front
80/100-21 51M
Tyre - rear
120/80-19 63M
Steering angle - left / right
42 / 42
Dimensions (L x W x H)
2,180 x 820 x 1,270 mm
Wheelbase
1,480 mm
Ground Clearance
345 mm
Seat height
960 mm
Fuel capacity
6.2 litres
Curb Mass
112.6 kg
Brakes & Suspension
Suspension - front
49 mm inverted telescopic fork with adjustable compression and rebound damping.
Suspension - rear
New Uni-Trak with adjustable dual-range (high/lowspeed) compression damping, adjustable rebound damping and adjustable preload.
Brakes - front
Single semi-floating 270 mm petal disc. Caliper: Brembo Dual-piston
Brakes - rear
Single 240 mm petal disc. Caliper: Single-piston
