2026 KX85 L

Engine type

Liquid-cooled, 2-stroke Single with KIPS

Displacement

84 cc

Bore x stroke

48.5 x 45.8 mm

Compression ratio

10.9:1 (low speed); 9.0:1 (high speed)

Valve/Induction system

Piston Reed valve

Fuel system

Carburettor: Keihin PWK 28

Ignition

Digital CDI

Starting

Primary kick

Lubrication

Petrol Mix

Frame type

Perimeter, high-tensile steel

Rake/Trail

29.2º / 117 mm

Wheel travel - front

275 mm

Wheel travel - rear

305 mm

Tyre - front

70/100-19 42M

Tyre - rear

90/100-16 52M

Steering angle - left / right

39° / 39°

Dimensions (L x W x H)

1,935 x 800 x 1,165 mm

Wheelbase

1,310 mm

Ground Clearance

330 mm

Seat height

865 mm

Fuel capacity

5 litres

Curb Mass

78.2 kg* | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

Suspension - front

43 mm inverted fork with adjustable compression and rebound damping

Suspension - rear

Uni Trak, single shock with adjustable dual-range (high/low-speed) compression damping, adjustable rebound damping and adjustable spring preload

Brakes - front

Single 240 mm petal disc. Caliper: Dual-piston

Brakes - rear

Single 220 mm petal disc. Caliper: Single-piston
